LEO XZS Stainless Steel Standard Centrifugal Pump Range

Large-frame source-version checks

The 11–22 kW model references include individual numerical hydraulic points, original large-frame outlines and separate dimension rows. XZS100-65-200/150 and /185 have conflicting W2, L and m3 dimensions between the printed table and current manufacturer model sheets; their pages show the printed version with a clear qualification. Confirm the exact supplied motor/frame drawing before installation. Current European manufacturer sheets identify XZS80-50-200/92 and XZS100-80-160/92 as 9.2 kW, while the local printed table labels the /92 rows 11 kW; local supplied-version confirmation remains outstanding. These exceptions have not been marked fully verified.

Additional verified 3 kW standard variants

These exact model codes are separately identified in the manufacturer table. Connection dimensions differ between standard versions; use the individual model page.

• LEO XZS65-50-160/30
• LEO XZS65-40-160/30
• LEO XZS80-65-125/30
• LEO XZS65-50-125/30

Source-rating qualification: the local /92 references print 11 kW, and the regional operating manual separately labels 12.1 kW input and 11 kW useful output for the four /92 codes. European manufacturer sheets explicitly list 9.2 kW for XZS80-50-200/92 and XZS100-80-160/92; their applicability to the paired EN733 codes and the locally supplied motors remains unconfirmed. These references do not establish an input-versus-output explanation for the disagreement. Confirm the supplied motor nameplate and applicable revision; do not infer a rating from the suffix.
